Brew your own IPA STOUT at home hotel brewpub with our premium beer making kit
Product Description
- 10HL Three vessel brew house with 20HL Hot water tank, steam heated
- 4*10HL CCTs + 2*10HL horizontal storage tanks
- Cooling unit: ILT + Chiller
- 100L CIP
- Control unit: Sienens S7-1200
Characters
i Brew house
-
Inner SUS304 Stainless Steel thickness: 3.0mm
-
External SUS 304 Stainless Steel thickness:2.0mm
-
Insulation: Polyurethane thickness:80mm.
-
Mash tun, Lauter tun, Boiling Kettle, Whirlpool tun in various combination
-
Equipment with tangent tube
-
Easy to clean and detachable sparging ball
-
360° CIP spraying ball
-
Stream heating, dimplate plate steam jacket thickness:3mm
-
Equipped with: Grain rake and agitator
-
Temperature measurement: Temperature Probe PT100
-
Food grade centrifugal pump VFD
-
Mash infusion process
ii Fermentation tank
-
Inner SUS304 Stainless Steel thickness: 3.0mm
-
External SUS 304 Stainless Steel thickness:2.0mm
-
Insulation:Polyurethane thickness:100mm.
-
Dimple plate cooling jacket,thickness:1.5mm
-
Dry hopping port
-
Stringent tank and Jacket leakage test by water and pressured gas, Tank design pressure is 0.3Mpa
-
Cone 60° resist compression design,dripping temperature drop
-
Carbonation port and stone for special request
-
Temperature display:PT100
-
Tri clamp discharge arm with butterfly valve
-
360° CIP spraying ball
Cooling Unit
1. Insulated glycol water tank with or without copper coil for glycol liquid holding and mixing
2. Efficiency chillers or refrigerators with fryon to supply cooling energy
3. Sanitary centrifugal pump for glycol water recycle among tanks and heat exchanger
4. All pipes, fitting, insulation materials are included
Control Unit
1. Mashing Pump on/off excluded VFD
2. Temperature display and Auto/Manu heating Control for brewhouse tanks
3. Auto/Manu Glycol Water Pump control
4. Auto/Manu Chiller control
5. Temperature display and Auto/Manu Control for FVs and BBTs
6. Temperature display and Control for GWT and CLT
7. Temperature controller, thermocouple, solenoid valves etc are included
8. PLC S7200 Siemens
Others
Portable CIP system for cleaning the tanks
Steam boiler for brewhouse heating
Water treatment for brew water
Oil free air compressor
Brewery COST
| production capacity | 100L | 200L | 300L | 500L | 1000L | 2000L |
| Floor space | ≥15m² | ≥25m² | ≥35m² | ≥50m² | ≥80m² | ≥120m² |
| Total power | 12kw | 12kw | 12kw | 15/36kw | 22/72kw | 31/144kw |
| Consumption of water(Max) | 0.2m³/h | 0.4m³/h | 0.5m³/h | 1.0m³/h | 1.5m³/h | 2.0m³/h |
| Total water consumption per day | 0.5m³/h | 1.0m³/h | 1.5m³/h | 2.5m³/h | 5.0m³/h | 10m³/h |
| Consumption of malt | 20kg | 40kg | 60kg | 100kg | 200kg | 400kg |
| Consumption of hops | 60g | 120g | 180g | 300g | 600g | 1.2kg |
| Yeast | 100g/1L | 200g/2L | 300g/3L | 500g/5L | 1kg/10L | 2kg/20L |
| Steam | | 0.017t/hr | 0.017t/hr | 0.05t/hr | 0.10t/hr | 0.20t/hr |
Jinan Shun Long Service
Before-Sales Service
1. Layout Design for new build brewery
Our experienced engineer( more than ten years) will provide the detailed layout according to your brewery, if needed, we will fly to your brewery at our cost.
2. Exist Brewery Expansion
Expansion of the brew house, beer tanks, or other parts, we will design and manufacture as per your exist brewery.
3. Effective business communication
Our sales team are young and rich of experience, we are full of passion, all of us have been in this business line for more than 8 years, and they are graduated from UK, Russia etc.
4. Brewing consultant
We also bult a good relation with Shandong university and other institutes who are expert in beer brewing, we are capable to provide the most advanced brewing technology.
After-Sales Service
1. Guarantee: 3 years
2. Installation: We shall send 1-2 enginees to your place for installtion and commission work in 20-30 ds.
3. We provide easy damage parts and life long technical support and after sales for free.
